Loreen Ebz160 Mining and Tunneling Development Machine Roadheader

Product usage
The machine is mainly used for coal roadway , semi-coal rock roadway and soft rock roadway and tunnel excavation,which coal rock hardness f≤8 ,to help realize continuous cutting, loading and transportation operations.The maximum positioning cutting section can reach 22m2and the gradeability is ±18°.

Technical parameters
Overall length9.9m
 Machine height1.8m
Total width3m
Machine weight52T
Production capacity4m³/min
Installed power250kW
Position the cutting maximum height4m
Position the cutting maximum width5.5m
Locate the maximum section of the cut22m2
Tractive effort≥310kN
Gantry height400mm
Ground clearance250mm
dinting depth 225mm
Gradeability±18°
Supply voltageAC1140V
System rating25MPa
Loreen Ebz160 Mining and Tunneling Development Machine Roadheader

Advantages
1.The cutting part has internal and external spray, water leakage detection and protection functions, the cutting motor has thermal protection, the cutting head has a truncated cone shape, and the tooth holder is arranged in a spiral shape.The internal spray seal adopts the world's leading sealing surface compensation technology with independent property rights, which completely solves the problem of unreliability of internal spray in the tunneling machine;
2.The plate working surface adopts double-sided inclination angle,
3.which is convenient for Shipping and clearing the bottom.
The overall design make machine strength is higher. The Charging device is directly driven by the low-speed hight or que motor by the curved three-toothed star wheel;The transport plane adopts middle double-chain, bilateral chain  transport structure, which is suitable for the transport of coal, semi-coal rock and rock materials. The base plate is linear and the transport is smooth. The scraper transport is directly driven by two low-speed and high-torque hydraulic motors;
4.The walking part adopts a highly integrated structure of the reducer and the hydraulic motor,small volume and high reliability, and the tensioning device adopts acombined structure of the tightening cylinder and the adjusting pad;
5.The electrical system is controlled by programmable controller and has the functions of new comprehensive protection system module to realize protection, dynamic display of liquid crystal Chinese characters, thermal protection of cutting motor, automatic system fault detection and memory.
6.The pump and operating valve of the hydraulic system adopt the world advanced  unit  import from German , which has the functions of constant power control, pressure cutting and load sensitive.
7.The rear support device realizes the long span support and improves the machine stability.
8.The walking part adopts a highly integrated structure of the reducer and the hydraulic motor to solve the problem of host self-moving when driving up and down the mountain;The gear ring of reducer box drives the sprocket directly, the volume is small, the torque is big, the tightener device USES the tightener oil cylinder and the adjustment mat composite structure.
9.The strength can be effectively guaranteed by using the military enterprises' matching caterpillar plate, and it can be customized according to different geological conditions.
10.The electrical system is controlled by PLC programming, and the dynamic display of liquid crystal Chinese characters has the function of automatic fault detection and memory, as well as the functions of voltage loss, short-circuit, motor overload, temperature, leakage detection, high and low speed interlocking of cutting motor.

The main parts configuration
Accessory nameSpecifications Modelmanufacture factory
Cutting machineYBUD-160/160-4/8(1140)Well-known domestic manufacturers
Oil pump motorYBK2-280M-4(660/1140)90KWWell-known domestic manufacturers
Electric cabinetKJZ-400/1140(660)E-4QingDaoTianXun
Explosion proof lampDGY20/36LShenYangGuangJiao
Scram buttonBZA2-5/36J(A)ShenYangGuangJiao
Hydraulic pumpA11V0145LRDS/11LREXROTH
Proportional multiple directional valvePSVHAWE
Two-way balancing valveFPOItaly
  Oil cylinder ShanDong ZhongLi
Hydraulic rubber hose Parker
Adapter connector Parker
A hydraulic motorIMA750 H3-A0-D40ITEMA
Walking reducerGFT80T3B185+BVD20REXROTH
Second planetary reducer Well-known domestic manufacturers
caterpillar chain BaoTou JunGong
Bearings SKF
PickΦ38Kennametal
Star wheel hydraulic motorIAM 1400 H4-A0-D40ITEMA
Loreen Ebz160 Mining and Tunneling Development Machine Roadheader


Our servicesThe company is responsible for the service concept of "You only need to purchase the product with confidence and satisfaction ,and the rest of the work is left to me", Attention to site before sale, quality in sale and training after sale. With the fastest speed, the best technology, the best attitude for you to present the gold medal characteristic service.

1>The company uses the overall resources and platform to provide machine sales, after-sale service, original spare parts supply, large and medium-sized machinery maintenance, technical consultation and on-site construction guidance.
2>The accessories can be supplied by the manufacturer directly, without intermediate fees.
3> The customer's expenditure is saved to the greatest extent. Besides, our company has a number of technical forces with national certificates. All the technical personnel have many years of field experience in underground and ground installation and debugging, and have a solid theoretical foundation and practical experience.
4>We could provide 7*24H service at the first time for technical support and original accessories supply.
5>On-site customization

You think, I do. According to the customer's production environment, safety needs, production requirements, and labor organization, the products are fully tailored to meet the customer's needs completely.
6>No worries for maintenance
You produce, I maintain. The professional team will carry out calendar maintenance on a regular basis. we will be fully responsible for refueling, replacement of accessories and regular maintenance.
7>Professional training
Your people, I train. Go to work site to train operators and maintenance workers, to ensure that the customer's operators can be skilled operation, maintenance workers to achieve professional level.
8>Take the command to undertake the installation and removal work
You order and I withdraw. The customer only needs to give us the next command to install and remove the equipment on site.
9>There is no barrier for small and large repairs
I am professional, I maintain. Complete maintenance according to customer requirements, carry out maintenance service without lifting well, and allow equipment to eliminate fault and restore normal operation in the shortest time, and minimize the impact on production time.
10>Serve with heart and soul

I will come when you need me.
Loreen Ebz160 Mining and Tunneling Development Machine Roadheader
Loreen Ebz160 Mining and Tunneling Development Machine Roadheader

FAQ

1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/P, (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, SGA
3: What about the delivery time?
A: 40 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 set.
